Biomass cua sov daws teeb meem biomass briquette burner, muaj lub zog huv huv biomass cua sov daws rau thermal lub zog xav tau qhov project.
Ua ntej VS Tom qab (hloov cov taws ncaj qha)
1. Txhim kho kev ua tau zoo
2. Txhim kho qhov ruaj khov ntawm cov khoom siv cua sov.
3. Tsis pub haus luam yeeb dub, muaj pa tawm tsawg, ua tau raws li cov qauv ib puag ncig stricter.
Cov ntaub ntawv kawm
3.0 M Kcal biomass gasification burner rau Longan kom qhuav hauv Thaib teb
1. Cov neeg qhua qhov chaw thiab Yuav Tsum Tau Ua
Siv hluav taws kub ncaj qha rau hluav taws kom muab hluav taws xob kub rau 5-tonVertical Cov Dej Kub Lub Txiab, mus rau 20 Ncu rau kom ntev ntev kom qhuav. Qhov teeb meem uas cov neeg siv ntsib: tsis ruaj khov ntawm dej kub, cov khoom tsim tawm tsis tuaj yeem tsis tuaj yeem xav tau, ua rau cov pa luam yeeb dub-ua haujlwm tsis zoo thiab muaj kuab paug.
 Longan qhov cub kom qhuav |  roj biomass |
2. Greenvinci Tshuaj
Ua lus pom zoo raws li cov ntaub ntawv (cov ntaub ntawv ua haujlwm, duab ua haujlwm, duab yeeb yaj kiab thiab lwm yam) muab los ntawm cov qhua tuaj noj mov. Txuas lus nrog cov qhua tuaj noj mov ces cov qhua tuaj hauv Suav tuaj xyuas peb lub tuam txhab thiab tshawb xyuas lub tshuab ua haujlwm ze ze. Muaj rooj sib tham los daws qhov teebmeem. Cov neeg siv khoom txaus siab nrog peb txoj kev daws teeb meem ces ua kev txiav txim. Thaum lub qhov cub hlawv tas, peb xa tus engineer los coj kev teeb tsa thiab kev ua haujlwm kom txog thaum lub tshuab hlawv ua haujlwm zoo nrog lub rhaub.
3. Tsog
Nruab rau lub Tsib Hlis, 2018, 3.0 M Kcal biomass gasification burner siv rau ntev ntev ziab hauv Chiang Maiv, Thaib. Kev siv cov ntoo txig nrog 25% noo noo los hloov cov nplaim hluav taws, kom muab hluav taws kub kub kom ua tau 95 ℃ dej kub kom ntev ntev kom qhuav los ntawm kev nthuav tawm cov cua sov ua haujlwm, ua haujlwm 24 teev ib hnub.
Tom qab kev hloov pauv:
1. Txhim kho kev ua tau zoo
2. Txhim kho qhov ruaj khov ntawm cov khoom siv cua sov.
3. Tsis pub haus luam yeeb dub, muaj pa tawm tsawg, ua tau raws li cov qauv ib puag ncig stricter.
 |  |
Hais txog peb
GreenVinci yog Tuam Tshoj ua cov chaw tsim khoom siv hluav taws xob txuag hluav taws xob nrog kev paub txog 10 xyoo, tsom rau kev muab cov tshuaj ntsuab rau cov cua sov, tau pab ntau tshaj 1000 tus neeg muas zaub hauv ntau tshaj 30 lub teb chaws thiab cheeb tsam.
Txhawm rau hloov cov nqi roj siab xws li Roj Nkev, diesel, LPG, LNG, CNG, FO thiab lwm yam Thiab muaj cov pa paug hnyav xws li cov thee, cov nplaim taws ncaj qha rau hluav taws, nrog cov roj biomass ua rau cov phooj ywg ib puag ncig, txuag nqi thiab kev ua haujlwm siab.
Kev lag luam txheeb xyuas (tus nqi hauv USD)
Roj | Chav Nyob | Tus nqi kub （ Kcal ） | Nqe (USD) | Qhov Tau Txais | Nqi （ USD / T ） | Tus nqi sib piv | Cov lus ceeb toom |
Hluav Taws Xob | kw | 860 | $ 0.12 | 700 | $ 84 | 114% | |
Diesel | kg | 10200 | $ 0.87 | 65 | $ 57 | 44% | |
Natrual roj | m 3 | 8500 | $ 0.49 | 80 | $ 39 | txuj | |
Pellet | kg | 4000 | $ 0.12 | 208 | $ 25 | -36% | |
tej daim ntoo | kg | 3600 | $ 0.07 | 230 | $ 16 | -59% | Pyrolysis |
Pob zeb | kg | 5500 | $ 0.08 | 178 | $ 14 | -64% |
* Coj tus nqi roj los tsim 1 T chav ua piv txwv, tus nqi yuav tau sib txawv vim tias tus nqi roj sib txawv thiab boiler thermal efficiency.
Peb cov khoom
Txoj ntsiab cai ua haujlwm
Biomass roj cia rau noj rau hauv lub tshuab ua kom kub siab, roj ib hlis roj, pyrolysis kev sib txuas, tsim kom muaj hluav taws thiab roj sib txuas - H 2 , CO, CH 4 thiab lwm yam, muaj kev sib txuas tag nrho, ntau dua kev siv hluav taws xob ntau txog li 90%.
 |  |  |
 |  |  |
| Parameter ntawm biomass gasifier | |||
| Los ntawm txhais tes tawm | |||
| Yam Tsis Muaj. | GV-240-G | GV-360-G | GV-480-G |
| Rau Cov Zis (Kcal) | 240 × 10 4 | 360 × 10 4 | 480 × 10 4 |
| Siv Tau Roj | ntoo chips, pellet | ntoo chips, pellet | ntoo chips, pellet |
| Kev tsuj roj | 380V | 380V | 380V |
| Cov kab ke pub mis | Pneumatic | Pneumatic | Pneumatic |
| Kev ntxuav tu | Phau Ntawv / Pib | Phau Ntawv / Pib | Phau Ntawv / Pib |
| Kev Siv Hluav Taws Xob | 9.25KW | 17KW | 21.5KW |
| Roj noj (h) | 600kg / h | 900kg / h | 1200kg / h |
| Qhov Coob | 2396 * 2800 * 3158mm | 3103 * 2340 * 3354mm | 3303 * 2340 * 3354mm |
| Khoom hnyav tag nrho | 5000kg | 10200kg | 10600kg |
| Nozzle los ntawm hauv av | 1252mm | 1416 hli | 1436 hli |
| Nozzles dia | 560 hli | 596mm | 636mm |
| Chamber kub | ≦ 900degree | ≦ 900degree | ≦ 900degree |
| Nplaim taws temprature | ≦ 1100 degree | ≦ 1100 degree | ≦ 1100 degree |
| Nozzle cov khoom siv | 310s / 316 SS | 310s / 316 SS | 310s / 316 SS |
| Tswjhwm system | Zaus hloov pauv, tsis siv neeg kub tas li, kov lub npov | Zaus hloov pauv, tsis siv neeg kub tas li, kov lub npov | Zaus hloov pauv, tsis siv neeg kub tas li, kov lub npov |
| Roj av taws ua kom sov | Siab kub - tiv thaiv corundum xis mas hauv ib qho nchuav molding | Siab kub - tiv thaiv corundum xis mas hauv ib qho nchuav molding | Siab kub - tiv thaiv corundum xis mas hauv ib qho nchuav molding |
| Cov kab ke pub mis | siv tawv conveyor | siv tawv conveyor | siv tawv conveyor |
Cov khoom lag luam yav tom ntej
Daim ntawv thov roj biomass dav: daim tawv ntoo, cov khib nyiab ntoo, pellet, pob zeb ci, xibtes plhaub, cashew plhaub thiab lwm yam.
Cov pa phem huv: "0" CO 2 ; ze rau "0" SO 2 ; tsuas yog thev naus laus zis, TSIS X txo los ntawm ntau dua 60%.
Lub sijhawm ua haujlwm ruaj khov: tsis siv neeg kaw kev kub siab, dhau ntawm qhov ntsuas kub thiab ultra-tsis tshua muaj dej. Interlock tswj.
Internet + ntse tswj: PLC, VFD, kov tshuaj ntsuam tswj - tsis siv neeg slag tawm, pub mis, qhov kub thiab lub siab tsis tu ncua, ua kom zoo thiab ruaj khov, qis ua haujlwm siv tsis tau.thiab tswj.
Cov ntawv thov
1) 3.6 M kcal biomass gasifier siv rau 6-T roj boiler hauv Chaw Tiv Thaiv Kev Tiv Thaiv Ib puag ncig （hloov roj） | 2) 7.2 M kcal Biomass gasifier siv rau 12-T roj boiler hauv Cov Khoom Noj Khoom Noj Hoobkas （hloov roj） | 3) 6 M kcal Biomass gasifier siv rau 10-T roj boiler hauv Chaw Tsim Tshuaj |
|  | |
4) 3.6 M kcal biomass gasifier txuas rau 3500kw thermal roj boiler hauv glycerin ntau lawm cog | 5) 3.0M kcal biomass gasigier txuas rau 5-tuj ntsug boiler hauv Thaib teb (hloov cov roj） | 6) 3.6 M kcal biomass gasifier txuas rau 6-T saw boiler hauv Cov Khoom Noj Khoom Noj & Dej Haus (hloov cov thee) |
|
|
|
1.Malaysia, 3.6 M Kcal nrog qeeb mentshis kom qhuav cov hmoov ntoo.
2.Surabaya, Indonesia, Phaj Mill, 1.2 M Kcal nrog 2-T thermal roj rhaub
3.Bangkok, Thaib Teb, Xovxwm Phaj Cog, 6.0 M Kcal nrog 10-tuj Gas Chav Boiler
4.Singapore, Hlau Rov Siv Cov Nroj Tsuag, 1.8 M Kcal nrog Qeeb Kom Qhuav Kiln rau kom qhuav Tsis yog hlau rau Cov Sludge
5.Txhob Isdias, Kev Tsim Txiaj Hlau, 2.4 M Kcal rau cov hluav taws kub cua qhwv
6.Bolivia, Lub Zeb Txiag, 1.2 M Kcal nrog Qhov Huab Cua Kub rau Qhuav Cov txhuv
.........
Peb cov kev pabcuam
FQA
1) Dab tsi yog lub sijhawm lav?
A: 1 xyoos rau qhov loj thiab lub neej ntev kev pheej yig tus txij nkawm.
2) Puas muaj kev xav tau rau cov khoom siv raw ??
A: qhov loj me <15cm ya="" raws=""><>
3) Cov neeg siv puas tuaj yeem pom cov khoom siv khiav hauv rhiav?
A: Yog lawm, peb muaj ntau qhov chaw khiav ze rau ntawm peb lub hoobkas, ntawm 1.2 M Kcal txog 9.0 M Kcal biomass burner uas tuaj yeem qhia tau li cas peb lub qhov cub ua haujlwm nrog boiler lossis lwm yam khoom siv thermal rau cov chaw sib txawv.
4) Lub sijhawm xa khoom?
A: Txog 30-40 hnub tom qab tso nyiaj (qhov kev txiav txim ceev tuaj yeem tham tau).
