Khoom Taw Qhia
Ntoo pellet kub dej boiler yog hom tshiab boiler nrog rau kev kub hnyiab thiab tshav kub pauv. Tsawg nqi khiav, feem ntau yog siv hauv tsev thiab kev lag luam los txhawb dej kub thiab lwm qhov cua sov. Nrog rau cov neeg txais kev pabcuam siab zoo tshaj, cov neeg ua haujlwm zoo, ua haujlwm tsawg, khiav lag luam thiab kho, khiav 30% ntawm 60% ntawm cov nqi hluav taws xob roj ntau dua cov roj hluav taws / roj / Hluav taws xob boilers.
Khoom khoom noj khoom haus
KHOOM | CLHS0.36-85 / 65-K | CLHS0.54-85 / 65-K | CLHS0.72-85 / 65-K | CHLS1.08-85 / 65-K | CHLS1.44-85 / 65-K | CHLS1.80-85 / 65-K | CHLS2.20-85 / 65-K | CHLS2.80-85 / 65-K | CHLS3.30-85 / 65-K | |
Tshaj Tus Nqi Nqis Calorific | 10 4 kcal | 30 | 45 | 60 | 90 | 120 | 150 | 180 | 240 | 300 |
Siab | Mpa | Atmospheric Siab | ||||||||
Thermal Efficiency | % | 92% | ||||||||
Kev haus luam yeeb hla | hli | 160 | 160 | 220 | 220 | 330 | 330 | 370 | 370 | 430 |
Cua system | kw | 0.75 | 0.75 | 0.9 | 1.1 | 1.5 | 2.2 | 2.2 | 3.0 | 4.0 |
Tsim Kev Txawj Ntse | kw | 2.2 | 2.2 | 3.0 | 3.0 | 4.0 | 4.0 | 5.5 | 7.5 | 7.5 |
Qhov cua sov | ㎡ | 1800-2500 | 2700-3500 | 4500-5500 | 6500-8000 | 9000-11000 | 12000-14000 | 15000-17000 | 21000-24000 | 30000-36000 |
Hopper muaj peev xwm | kg | 200 | 300 | 400 | 400 | 500 | 500 | 600 | 800 | 800 |
Tshaj tawm ntawm ib qho | hli | 89 | 89 | 102 | 102 | 120 | 120 | 140 | 140 | 160 |
Dej tawm los (△ t40 ℃) | T / h | 6.5 | 11 | 13 | 19.5 | 26 | 32 | 39 | 52 | 65 |
Nyhav | kg | 1380 | 1520 | 1880 | 2350 | 2850 | 3350 | 3850 | 4380 | 6350 |
Boiler Loj (L * W * H) | hli | 3100 * 700 * 1700 | 3300 * 800 * 1800 | 3500 * 900 * 1900 | 3800 * 1000 * 2070 | 4100 * 1100 * 2240 | 4400 * 1200 * 2390 | 4700 * 1300 * 2550 | 5300 * 1500 * 2850 | 5900 * 1700 * 3100 |
Khoom Nta
1) Siv cov khoom siv roj tua hluav taws ua kom lub cev kub hnyiab, thiab siv cov pa pa kub cua kom pauv cov cua kub tshiab rau hauv lub chamber kev sib txuas, uas yog 5% tsawg zog dua cov cua txias.
2) Cov cuab yeej siv phom sij hauv plob hav zoov tau ua kom paub tseeb tias tsis muaj pa luam yeeb thiab plua plav dawb.
3) Tsim kom muaj kev tsim ntawm "multi-lub tshuab hluav taws xob, ntau qhov rov qab", zoo heev rau lub sijhawm thiab qhov chaw sib txauv, ua kom lub thermal efficiency nce mus txog 92% thiab cov pa kub cua kub qis tshaj 120 degrees los ua kom tau qhov siab tshaj plaws kev txuag nyhuv.
4) Cov kev tswj xyuas qhov ntsej muag tag nrho: kev tuaj yeem tiv cav, kev pub noj tsis siv, kev siv dej tsis zoo, kub kub, tiv thaiv dej tsis muaj teeb meem.
5) Kev tsim cov khoom siv ua kom muaj kev tiv thaiv ntau yam, tiv thaiv kev tawg, hluav taws rov qab, siab thiab lwm yam teeb meem kev ruaj ntseg.
Kev qhia kev cob qhia
Kev Ntsuam Economic
Cov dej kub kub npau npau ib lim piam 60 degrees dej kub (pib kub 20 degrees) yuav tsum muaj rau ib tuj ntawm kev sib piv txhua yam zog.
Cov nram qab no yog cov nqi sib piv ntawm ntau lub luv fuels: (RMB)
Roj | 0 # Diesel | Natural roj | Hluav taws xob | Thee | Biomass pellet |
Cov nqi tshav kub | 10200kcal / KW | 8500 / kg | 860kcal / Nm 3 | 5500kcal / kg | 4000kcal / kg |
Xav tau roj ntau ntau | 4.5kgs | 5Nm 3 | 46kw | 11kgs | 12kgs |
Roj nqe | 8 / kg | 4.8 / Nm3 | 1 / kwh | 1 / kg | 0.9 / kg |
Cov nqi tshav kub hloov | 88% | 95% | 100% | 70% | 90% |
Ruv nqi (RMB) | 36 | 24 | 46 | 11 | 10.8 |
Nqi txuag | 22.8 | 10.8 | 32.8 | 0.2 | |
Nqi txuag% | 63% | 45% | 71% | 2% |
Cov duab ua haujlwm zoo
Yam khoom tsim nyog
Xa, Shipping Thiab Pab
Lus nug
Q1.Application ntawm lub Pellet Kub Dej Boiler?
A: Siv dav dav hauv cov chaw ntiav pw, tsev tos qhua, chaw da dej, cov neeg lom zem, chaw zoo nkauj, vaj tse, vaj tse, tsev, factories, tsev kawm ntawv thiab cov tuam txhab muaj dej kub, da dej thiab cua sov.
Q2. Hom Phem Ywg Siv Tau Siv Hauv Qhov Boiler no
A.Customer tuaj yeem xaiv txhua hom biomass pellet, xws li ntoo pellet, pom cov plua plav pellet, straw pellet, pob kws cob pellet thiab lwm yam.
Q3.Muaj Puas yog Tiv Thaiv Daws Teeb Meem?
Tau, nws muaj ntau yam kev tiv thaiv kev tiv thaiv kom tsis txhob muaj kev phom sij thaum siv lub boiler. Muaj qhov kev pab cuam nres tsheb tsis zoo thiab kub sensor. Txhua cov txheej txheem yuav raug saib xyuas thiab tiv thaiv.
Q4.How ua li cas kuv nruab ib lub chimney?
A: Yog tias koj tsis paub txhim kho qhov chimney, thov hu rau peb nrog koj kos duab kos duab. Peb tus engineer yuav tsim thiab txhawb koj los txhim kho txoj cai chimney.
Q5.Do Kuv Yuav tsum Nrua Ib Daim Plua Plav Los?
A: Peb cov khoom tsim muaj hluav taws xob rov qab ntaus khoom, tseem muaj dej plua av collector. Rau feem ntau cov neeg muas zaub, tsis tas yuav tsum nruab ib qho khoom ntxiv.
Q6.Delivery Sijhawm thiab Thauj Nyiaj?
Lub sij hawm xa tuaj nyob ntawm seb qhov txiav txim kom muaj nuj nqis npaum li cas thiab peb lub caij nyoog tsim khoom. Kev txiav me me feem ntau yuav xa tuaj tsis pub dhau 7 hnub.
Lub sij hawm thauj yog feem ntau 30 ~ 50 hnub.
Q7: Warranty?
A: Lub sij hawm Warranty yog 12 lub hlis. Peb muab kev hloov pauv rau qhov chaw tawg (tsis suav kev ua rau neeg tsim)
